Electromagnetic Flow Meter
FW: 842018/842009
24h Flow
The "24h Flow" option measures the total flow (FTot) for 1 day (24 hours)
and logs at midnight (12 PM). Contact MJK for detailed information.
Valid settings are "No" and "Yes" (default is "No").
Status
The "Status" option provides an overview of the in- and output status. The
check boxes can contain four different characters to indicate the current
status at that very moment:
X A cross (X) in a check box indicates an active state
/ A blinking forward slant (/) in a check box indicates that the input/
output is in the process of being activated. Eventually it turns into a
steady X.
\ A blinking backward slant (\) in a check box indicates that the
input/output is in the process of being de-activated. Eventually the
check box is cleared
.
An empty check box indicates a de-activated state.
Flow Direction
Mechanical Relay (DO2)
Opto Relay (DO1)
Display only
Not in use
Back Select OK
Mechanical Relay (DO2) Opto Relay (DO1) Display only
Relay Function
NO
NC
Back Select OK
Empty Pipe
Mechanical Relay (DO2)
Opto Relay (DO1)
Display only
Not in use
Back Select OK
Delay
00010 Sec
Back Select >
Delay
00010 Sec
Back Select >
Delay
00010 Sec
Back Select >
Mechanical Relay (DO2) Opto Relay (DO1) Display only
Relay Function
NO
NC
Back Select OK
Delay
00010 Sec
Back Select >
Delay
00010 Sec
Back Select >
Delay
00010 Sec
Back Select >
Type Password
0000
Back Select >
Service Menu
Sensor Calibration Code
Converter SW Ver.
Product Data
Reset Counter Time
Internal Meas. & Cal.
Minimum Velocity
Calibrate Flow now
Calibrate Volume
Calibrate mA
Test Velocity
Freeze Coil
Read Event Log
Back on Stock
Back
Select OK
OK
Only f
or ter
minal use
Must not be surrended
A
B
C
D
E
Date Modification
Scale:
MJK AUTOMATION A/S
Byageren 7
DK-2800 Nñrum
Fax: +45 45 56 06 46
Tel.: +45 45 56 06 56 Date:
Constructor:
Part no.:
Software version
Skala for tegning
Menu system for MagFlux Converter
Konverter Setup
Service Menu, Flow Direction, Empty Pipe
2006 - 09 - 20
841010
KJ/LSP
Path: Main Menu -> Converter setup -> Flow Direction / Empty Pipe / Service Menu / Status
Relay Function
NO
NC
Back Select >
Relay Function
NO
NC
Back Select >
Status
DO1 Not in use
DO2 R Totalizer Forward
DI R Totalizer Forward
mA output 6.250 mA
Back Select OK
DO1 Not in use
Digital output D01 is active (an empty check box).
DO2 X Totalizer Forward
Digital output D02 for Totalizer Forward is activated (a ticked check
box).
DI Totalizer Forward
Digital input DI for Totalizer Forward is active (an empty check box)
mA output 6.250 mA
The present analog output current is 6.250 mA.
