56 EN 3.05 MagFlux Manual 1212
Electromagnetic Flow Meter
The data log contains:
• Date
• Time
• Flow values
In case of a power failure, the data logger continues when power returns.
If more converters are connected to one Display Unit, each converter has
its own individual log interval and can be sorted.
All converters share the same memory of 160.000 entry points.
The log data can be shown on the Display Unit or be stored in an external
CSV file. MJK-Field Link software is needed for transfer of data into CSV
file format via the USB port in the display unit. The format can be read in
for example Microsoft
® Excel ® (see Appendix B on page 120 for details).
An example of the log capacity of one sensor versus the time interval is
shown in the following table.
Log interval Log capacity
Seconds Minutes Hours Days
10 - 444,45 18,51
30 - 1333,34 55,55
- 1 2667 111
- 5 13333 555
- 10 26667 1111
- 30 80000 3333
- 60 160000 6667
