Electromagnetic Flow Meter
Empty Pipe
A signal and/or an alarm can be set, when the sensor becomes practically
empty (see also pages
19 - 22 incl.), or if the conductivity drops below 5 µS/
cm.
Flow Direction
Mechanical Relay (DO2)
Opto Relay (DO1)
Display only
Not in use
Back Select OK
Mechanical Relay (DO2) Opto Relay (DO1) Display only
Relay Function
NO
NC
Back Select OK
Empty Pipe
Mechanical Relay (DO2)
Opto Relay (DO1)
Display only
Not in use
Back Select OK
Delay
00010 Sec
Back Select >
Delay
00010 Sec
Back Select >
Delay
00010 Sec
Back Select >
Mechanical Relay (DO2) Opto Relay (DO1) Display only
Relay Function
NO
NC
Back Select OK
Delay
00010 Sec
Back Select >
Delay
00010 Sec
Back Select >
Delay
00010 Sec
Back Select >
Type Password
0000
Back Select >
Service Menu
Sensor Calibration Code
Converter SW Ver.
Product Data
Reset Counter Time
Internal Meas. & Cal.
Minimum Velocity
Calibrate Flow now
Calibrate Volume
Calibrate mA
Test Velocity
Freeze Coil
Read Event Log
Back on Stock
Back
Select OK
OK
Only f
or ter
minal use
Must not be surrended
A
B
C
D
E
Date Modification
Scale:
MJK AUTOMATION A/S
Byageren 7
DK-2800 Nñrum
Fax: +45 45 56 06 46
Tel.: +45 45 56 06 56 Date:
Constructor:
Part no.:
Software version
Skala for tegning
Menu system for MagFlux Converter
Konverter Setup
Service Menu, Flow Direction, Empty Pipe
2006 - 09 - 20
841010
KJ/LSP
Path: Main Menu -> Converter setup -> Flow Direction / Empty Pipe / Service Menu / Status
Relay Function
NO
NC
Back Select >
Relay Function
NO
NC
Back Select >
Status
DO1 Not in use
DO2 R Totalizer Forward
DI R Totalizer Forward
mA output 6.250 mA
Back Select OK
The available output options for "Empty Pipe" are:
Mechanical Relay (DO2)
Opto Relay (DO1) (light-triggered electronic relay)
Display only (signals to the Display Unit only)
Not in use (the Empty Pipe option is not being used)
Delay
A delay in seconds can be set to compensate for positive and negative
spikes in the flow. The lenght is the time between an incident and set-
ting an alarm.
Relay Function
NO (Normally Open) determines the relay state under normal conditions.
NC (Normally Closed) determines the relay state under normal conditions.
