EN 3.05 MagFlux Manual 1212
Electromagnetic Flow Meter
3. Then select "Service Menu" and "Sensor Calibration Code".
Converter Setup
Converter Setup
Minimum Flow
Averaging
Units
mA Output
R Totalizer Forward
R Totalizer Reverse
R Totalizer Sum
NR Totalizer Forward
NR Totalizer Reverse
NR Totalizer Sum
Batch Counter 1
Batch Counter 2
High Flow
Low Flow
Flow Direction
Empty Pipe
Status
Service Menu
Back
Select
OK
Service Menu
24h Flow
Sensor Calibration Code
|
Back
Select
>
S/N not entered
Set Flow Direction
Follow Arrow A
Follow Arrow B
Back
Select
OK
MagFlux1
Flow 0.00 m
3
/h
FTot 00.000 m
3
Select Setup
Service Menu
Sensor Calibration Code
Converter SW Ver.
Product Data
Reset Counter Time
Internal Meas. & Cal.
Minimum Velocity
Calibrate Flow now
Calibrate Volume
Calibrate mA
Test Velocity
Freeze Coil
Read Event Log
Back on Stock
Back
Select
OK
Set Flow Direction
Follow Arrow A
Follow Arrow B
Back
Select
OK
Sensor Calibration Code
Sensor Calibration Code
dw5uq4
Back
Select
OK
Sensor Calibration Code
A
B
A
B
4. Enter the calibration code read from the converter label (or pass
through or change the displayed calibration code) and then press OK.
See also details regarding the calibration code on page
5. Select the correct flow direction in the "Set Flow Direction" menu and
press OK.
