Xylem Magflux Electromagnetic Flow Meter User Manual
Page 50
50
EN 3.05 MagFlux Manual 1212
Electromagnetic Flow Meter
Batch 1
Timer for batch volume 1
Batch 2
Timer for batch volume 2
Batch 1 DN
Displays the missing amount of Batch volume 1 (DN = down)
Batch 2 DN
Displays the missing amount of Batch volume 2 (DN = down)
Batch 1Cnt
Batch 1 Counts (number of batches)
Batch 2 Cnt
Batch 2 Counts (number of batches)
Batch 1 Vol
Batch 1 Volume
Batch 2 Vol
Batch 2 Volume
Clock
Time and date
The size of the display lines will automatically increase or decrease as the
number of display lines is removed or added to maximize the field of view
for the measured values
