Electromagnetic Flow Meter
FW: 842018/842009
Converter Setup
"Converter Setup" provides configuration options for volumes, batches,
units, etc. See detailed descriptions in the following sections and in the
overview pages at the end of this manual.
1. Press the up/down keys to highlight the required menu line (here: Con-
verter Setup) and then press OK to select it.
Specify Main Screen
Factory Settings
Data Logger
Password
Set Sensor Name
Converter Setup
Display Setup
Back Select OK
Main Menu
Converter Setup
2. Press the up/down keys to highlight the required option and then press
OK to select it.
Converter Setup
Converter Setup
Minimum Flow
Averaging
Units
mA Output
R Totalizer Forward
R Totalizer Reverse
R Totalizer Sum
NR Totalizer Forward
NR Totalizer Reverse
NR Totalizer Sum
Batch Counter 1
Batch Counter 2
High Flow
Low Flow
Flow Direction
Empty Pipe
Status
Service Menu
Back
Select OK
Minimum Flow
24h Flow
The available options are described in detail in the following sections.
