48 EN 3.05 MagFlux Manual 1212
Electromagnetic Flow Meter
Specify Main Screen
The "Specify Main Screen" menu allows you to customize the MagFlux ®
display to suit your requirements. You can add and remove the five avail-
able display lines and configure them individually.
Select Line
Line 1 - Sensor Name
Line 2 - Flow
Line 3 - FTot
Line 4
Line 5
Back Select
OK
Specify Main Screen
Select Line Content
Not in use
Flow
RFTot
RRTot
RTTot
FTot
RTot
Cnt
Flow Direction
Batch 1
Batch 2
Batch 1 Dn
Batch 2 Dn
Batch 1 Cnt
Batch 2 Cnt
Batch 1 Vol
Batch 2 Vol
Clock
Back Select OK
1. Press the up/down keys to highlight the required menu line and then
press OK to select it.
2. Press the up/down keys to highlight the required option and press OK.
