Basic Installation and User’s Guide for the Millennium II Controller
Issue 3 January 2008 56
cell battery voltage as a function of
temperature.
Enabled Enables or Disables the Thermal
Compensation Feature. Move the cursor to the
field and use the <+> or <-> key to Enable or
Disable. Press to save the change.
High Temp
Comp
This feature allows the system to compensate
for high temperatures.
Volt Step
Down Battery step temperature can be set from 113-
185F. At this temperature, the system voltage
is reduced by 0.17 X # of cells/string.
High Comp
Limit This sets the maximum temperature for which
thermal compensation is active.
Decrease This sets the slope (mV/degC) for high
temperature compensation.
Nominal
Temp This field set the temperature at which no
compensation is required. The system voltage
is at the setpoint float mode.
Low Temp Comp This feature allows the system to compensate
for low temperatures.
Low T
Comp This enables or disables the low temperature
compensation feature.
Low Comp
Limit This sets the minimum temperature for which
thermal compensation is active.
Increase This sets the slope (mV/degC) for low
temperature compensation.
8. Recharge Current
Limit
This feature sets the total amount of current
that will be allowed to recharge the batteries.
Limit The configuration of this field enables or
disables the feature.
Limit to This programmable value sets the maximum
amount of recharge current (in Amps) that
will be allowed for recharging the batteries.
The range is from 10 – 1000A.
9. Contactors Up to three optional LVD devices can be
connected to a Millennium and configured
