GE Industrial Solutions Entellisys 4.0 Integrator's Guide User Manual
Page 67
67
3
506A
Synch Check Reserved (14 items)
---
---
---
F001
0
5078
...Repeated for module number 2
5096
...Repeated for module number 3
50B4
...Repeated for module number 4
50D2
...Repeated for module number 5
50F0
...Repeated for module number 6
510E
...Repeated for module number 7
512C
...Repeated for module number 8
514A
...Repeated for module number 9
5168
...Repeated for module number 10
5186
...Repeated for module number 11
51A4
...Repeated for module number 12
ZSI Option Settings (Read/Write Setting)
51C2
ZSI Option
0 to 2
---
1
F732
0 (ST ZSI)
ZSI Zone Enables (Read/Write Setting) (4 modules)
51C4
ZSI Zone X Enabled
0 to 1
---
1
F126
0 (No)
51C5
ZSI Zone Enable Reserved (4 items)
---
---
---
F001
0
51C9
...Repeated for module number 2
51CE
...Repeated for module number 3
51D3
...Repeated for module number 4
Simple Network Time Protocol (Read/Write Setting)
51DD
Simple Network Time Protocol (SNTP) Server
IP Address
0 to 4294967295
---
1
F003
0
51DF
Simple Network Time Protocol (SNTP) Server
Time Zone Bias
-46800 to 43200
---
900
F004
0
ZSI ST Tier Settings (Read/Write Setting) (30 modules)
5200
SRC X ST ZSI Zone 1 Tier Settings (16 items)
0 to 3
---
1
F733
0 (ZSI Tier 0)
5210
SRC X ST ZSI Zone 2 Tier Settings (16 items)
0 to 3
---
1
F733
0 (ZSI Tier 0)
5220
SRC X ST ZSI Zone 3 Tier Settings (16 items)
0 to 3
---
1
F733
0 (ZSI Tier 0)
5230
SRC X ST ZSI Zone 4 Tier Settings (16 items)
0 to 3
---
1
F733
0 (ZSI Tier 0)
5240
SRC X ST ZSI Tier Settings Reserved (16
items)
---
---
---
F001
0
5250
...Repeated for module number 2
52A0
...Repeated for module number 3
