Modbus Memory Map 110
3 DB35 ...Repeated for module number 254
DB37 ...Repeated for module number 255
DB39 ...Repeated for module number 256
PLC Interface (Read/Write)
DC00 PLC Input States (16 items) 0 to 65535 --- 1 F500 0
PLC Interface (Read Only)
DC10 Virtual Input States (2 items) 0 to 65535 --- 1 F500 0
DC12 Virtual Output States (30 items) 0 to 65535 --- 1 F500 0
DC30 Contact Input States (8 items) 0 to 65535 --- 1 F500 0
DC38 Contact Output States (8 items) 0 to 65535 --- 1 F500 0
DC40 Breaker Control Flex Operand States (25
items) 0 to 65535 --- 1 F500 0
DC59 Bus Differential Flex Operand States (2
items) 0 to 65535 --- 1 F500 0
DC5B Reserved (12 items) --- --- --- F001 0
DC67 Ground Fault Flex Operand States (12 items) 0 to 65535 --- 1 F500 0
DC73 High Current Flex Operand States (6 items) 0 to 65535 --- 1 F500 0
DC79 Reserved (3 items) --- --- --- F001 0
DC7C High Current Transient Flex Operand States
(6 items) 0 to 65535 --- 1 F500 0
DC82 HRGF Detection Flex Operand States (6
items) 0 to 65535 --- 1 F500 0
DC88 HRGF Location Flex Operand States 0 to 65535 --- 1 F500 0
DC89 IOC Flex Operand States (4 items) 0 to 65535 --- 1 F500 0
DC8D LT Overcurrent Flex Operand States (6 items) 0 to 65535 --- 1 F500 0
DC93 MSGF Overcurrent Flex Operand States (2
items) 0 to 65535 --- 1 F500 0
DC95 Multi Point RELT Flex Operand States 0 to 65535 --- 1 F500 0
DC96 Over Frequency Flex Operand States (12
items) 0 to 65535 --- 1 F500 0
DCA2 Over Voltage Flex Operand States (12 items) 0 to 65535 --- 1 F500 0
DCAE Phase Loss Flex Operand States (12 items) 0 to 65535 --- 1 F500 0
DCBA Power Reversal Flex Operand States (12
items) 0 to 65535 --- 1 F500 0
