59
3 2B1B SRC X CT Rating 0 to 65535 --- 1 F001 0
2B1C SRC X Breaker Type 0 to 1 --- 1 F715 0 (UL)
2B1D SRC X NodeProt Protection Config 0 to 65535 --- 1 F705 0
2B1E SRC X Node Firmware Version 0 to 655.35 --- 0.01 F001 0
2B1F SRC X Hardware Version 0 to 255 --- 1 F001 0
2B20 SRC X Message Protocol Version 0 to 655.35 --- 0.01 F001 0
2B21 SRC X Product Type 0 to 2 --- 1 F716 0 (Low Voltage
Switchgear)
2B22 SRC X NodeProt Rating Switch 0 to 65535 --- 1 F001 0
2B23 SRC X NodeProt LT Setting 0 to 655.35 --- 0.01 F001 0
2B24 SRC X NodeProt IOC Threshold Setting 0 to 655.35 --- 0.01 F001 0
2B25 SRC X NodeProt Ground Fault Setting 0 to 1 --- 1 F001 0
2B26 SRC X NodeProt Short Time Setting 0 to 1 --- 1 F001 0
2B27 SRC X Node Internal Diagnostics 0 to 65535 --- 1 F701 0
2B28 SRC X Node System Diagnostics 1 0 to 65535 --- 1 F702 0
2B29 SRC X Node System Diagnostics 2 0 to 65535 --- 1 F703 0
2B2A SRC X Node Hardware Diagnostics 0 to 65535 --- 1 F704 0
2B2B SRC X Node Physical Status 0 to 65535 --- 1 F708 0
2B2C SRC X Node Logic and Trip Status 0 to 65535 --- 1 F709 0
2B2D SRC X Node Last Trip Sequence Number 0 to 4294967295 --- 1 F003 0
2B2F SRC X Reflected CPU Diagnostics 0 to 65535 --- 1 F706 0
2B30 SRC X Reflected CPU 0 Command 0 to 65535 --- 1 F707 0
2B31 SRC X Reflected CPU 1 Command 0 to 65535 --- 1 F707 0
2B32 SRC X Fan Status 0 to 1 --- 1 F108 0 (Off)
2B33 SRC X CT Rating Node Report 0 to 65535 --- 1 F001 0
2B34 SRC X Node Serial Number --- --- --- F205 (none)
2B3A SRC X Phase A Frequency 0 to 655.35 Hz 0.01 F001 0
2B3B SRC X Phase B Frequency 0 to 655.35 Hz 0.01 F001 0
2B3C SRC X Phase C Frequency 0 to 655.35 Hz 0.01 F001 0
2B3D SRC X Topology 0 to 15 --- 1 F001 1
2B3E Reserved (2 items) --- --- --- F001 0
2B40 SRC X Node Status Reserved (38 items) --- --- --- F001 0
2B66 ...Repeated for module number 2
