1.5 Assumptions
These operating instructions assume that you are using a an AF-650 GP or AF-600 FP frequency converter with a DeviceNet option module installed in the drive..
It is also assumed that you are using a PLC or PC based scanner equipped with a serial communication card supporting all the DeviceNet communication services
required by your application. Furthermore, it is assumed that all requirements stipulated in the DeviceNet standard as well as those set up in the AC Drive Profile
and those pertaining to the frequency converter are strictly observed as well as all limitations therein fully respected.
1.6 Hardware
These operating instructions relate to the DeviceNet option Model No. OPCDEV.
1.7 Background Knowledge
The GE DeviceNet is designed to communicate with any master abiding by the DeviceNet standard. It is therefore assumed that you have full knowledge of the
PC or PLC you intend to use as a master in your system. Any questions pertaining to hardware or software produced by any other manufacturer is beyond the
scope of these operating instructions. If you have questions about how to set up master - master communication or communication to a non-GE slave, please
consult the appropriate documentation.
1.8 Available Literature
For additional AF-6 Series Drives information please visit www.geelectrical.com/drives.
1.9 Abbreviations
ACK ACKnowledge
BOC Bus Off Counter
BOOL BOOLean expression
CAN Controller Area Network
CSMA/CA Carrier Sense Multiple Access/Collision Avoidance
COS Change of State
CTW Control Word
EDS Electronic Data Sheet
EMC Electromagnetic Compatibility
ETR Electronic Thermal Relay
FIFO First In First Out
HF High Frequency
HPFB High Performance Field Bus
I/O Input/Output
ISO International Standards Organization
LCD Liquid Crystal Display
LED Light Emitting Diode
LSB Least Significant Bit
MAC ID Media Access Control IDentifier
MAV Main Actual Value
MRV Main Reference Value
MSB Most Significant Bit
N/A Not Applicable
ODVA Open DeviceNet Vendor Association
OSI Open Systems Interconnection
PC Personal Computer
PCD Process Data
PIW Peripheral Input Word
PLC Programmable Logic Control
PNU Parameter Number
PPO Parameter-Process Data Object
QW Peripheral Output Word
SINT Signed Integer
STW Status Word
VSD Variable Speed Drive
UDINT Unsigned Double Integer
UNIT Unsigned Integer
USINT Unsigned Short Integer
