6.2 Parameter List
Par. No. # and Description Default value Range Conversion
index Data type
Par. O-00 Enabled options All [1] [0 - 7] - 5
par. O-01 Control Site Dig. & ctrl. word [0] [0 - 2] - 5
par. O-02 Control Word Source Drive RS485 [0] [0 - 4] - 5
par. O-03 Control Word Timeout Time 1s 0.1-18000 -1 7
par. O-04 Control Word Timeout Function Off [0] [0 - 10] -1 5
par. O-05 End-of-Timeout Function Hold set-up [0] [0 - 1] - 5
par. O-06 Reset Control Word Timeout Do not reset [0] [0 - 1] - 5
par. O-07 Diagnosis Trigger Disable [0] [0 - 3] - 5
par. O-10 Control Word Profile Drive protocol [0] [0 - x] - 5
par. O-50 Coasting Select Logic OR [3] [0 - 3] - 5
par. O-51 Quick Stop Select Logic OR [3] [0 - 3] - 5
par. O-52 DC Brake Select Logic OR [3] [0 - 3] - 5
par. O-53 Start Select Logic OR [3] [0 - 3] - 5
par. O-54 Reversing Select Logic OR [3] [0 - 3] - 5
par. O-55 Set-up Select Logic OR [3] [0 - 3] - 5
par. O-56 Preset Reference Select Logic OR [3] [0 - 3] - 5
par. O-90 Bus Jog 1 Speed 100 rpm
0 - par. F-17 Motor Speed
High Limit [RPM]
67 6
par. O-91 Bus Jog 2 Speed 200 rpm
0 - par. F-17 Motor Speed
High Limit [RPM]
67 6
par. DN-00 DeviceNet Protocol DeviceNet [1] [0 - 1] - 5
par. DN-01 Baud Rate Select 125 Kbps [20] [20 - 22] - 5
par. DN-02 MAC ID 63 0 - 63 0 5
par. DN-05 Readout Transmit Error Counter 0 0 - 255 0 5
par. DN-06 Readout Receive Error Counter 0 0 - 255 0 6
par. DN-07 Readout Bus Off Counter 0 0 - 1000 0
par. DN-10 Process Data Type Selection [0]/[2] [0 - 3] 0 5
par. DN-11 Process Data Config Write 0 list 0 5
par. DN-12 Process Data Config Read 0 list 0 5
par. DN-13 Warning Parameter 0 0 - FFFF 0 5
par. DN-14 Net Reference Off [0] [0 - 1] - 5
par. DN-15 Net Control Off [0] [0 - 1] - 5
par. DN-20 COS Filter 1 0 0 - FFFF 0 6
par. DN-21 COS Filter 2 0 0 - FFFF 0 6
par. DN-22 COS Filter 3 0 0 - FFFF 0 6
par. DN-23 COS Filter 4 0 0 - FFFF 0 6
par. DN-31 Store Data Values Off [0] [0 - 2] - 5
par. DN-32 Devicenet Revision - - - 6
par. DN-33 Store Always Off [0] [0 - 1] - 5
par. DR-90 Alarm Word 0 0 - FFFF 0 7
par. DR-92 Warning Word 0 0 - FFFF 0 7
