Contents
1 Introduction
3
Safety Note 4
Assumptions 6
Hardware 6
Background Knowledge 6
Abbreviations 6
2 How to Install
7
Cabling 7
Installation of the DeviceNet option module 10
3 How to Configure the System
11
Configure the Master 13
Configure the Frequency Converter 13
4 How to Control the Frequency Converter
15
DeviceNet Process Control Modes 15
I/O Assembly Instances 16
Process Data 16
ODVA Control Profile 17
GE Drive Control Profile 20
5 How to Access the Parameters
27
Explicit Messages 27
Object Classes 27
DeviceNet Object Classes 27
Drive Object Classes 35
6 Parameters
37
Parameter List 44
Data Types Supported 45
7 Application Examples
47
Example: Working with Instance 101/151 Process 47
8 Troubleshooting
49
Troubleshooting 49
Index 56
AF-600FP /650 GP DeviceNet Operating Instructions
1
