DN-12 Process Data Config Read
Select the process read data for I/O Assembly Instances 101/151. Elements [2] and [3] of this array can be selected. Elements [0] and [1] of the array are fixed.
Option: Function:
DN-13 Warning Parameter
Range: Function:
0 N/A* [0 - 65535 N/A] View a DeviceNet-specific Warning word. One bit is assigned to every warning.
Bit: Meaning:
0 Bus not active
1 Explicit connection timeout
2 I/O connection
3 Retry limit reached
4 Actual is not updated
5 Network off
6 I/O send error
7 Initialization error
8 No bus supply
9 Bus off
10 Error passive
11 Error warning
12 Duplicate MAC ID Error
13 RX queue overrun
14 TX queue overrun
15 Network overrun
DN-14 Net Reference
Read only from Keypad
Option: Function:
Select the reference source in Instance 21/71 and 20/70.
[0] * Off Enables reference via analog/digital inputs.
[1] On Enables reference via the network.
DN-15 Net Control
Read only from Keypad
Option: Function:
Select the control source in Instance 21/71 and 20-70.
[0] * Off Enables control via analog/digital inputs.
[1] On Enable control via the network.
DN-20 COS Filter 1
Range: Function:
0 N/A* [0 - 65535 N/A] Sets up the filter mask for the status word. When operating in COS (Change-Of-State), it is possible to filter
out bits in the status word that should not be sent if they change.
DN-21 COS Filter 2
Range: Function:
0 N/A* [0 - 65535 N/A] Sets up the filter mask for the Main Actual Value. When operating in COS (Change-Of-State), it is possible
to filter out bits in the Main actual value that should not be sent if they change.
DN-22 COS Filter 3
Range: Function:
0 N/A* [0 - 65535 N/A] Sets up the filter mask for PCD 3. When operating in COS (Change-Of-State), it is possible to filter out bits
in PCD 3 that should not be sent if they change.
