DN-01 Baud Rate Select
Select the fieldbus transmission speed. The selection must correspond to the transmission speed of the master and the other network nodes.
Option:
Function:
[16]
10 Kbps
[17]
20 Kbps
[18]
50 Kbps
[19]
100 Kbps
[20] *
125 Kbps
[21]
250 Kbps
[22]
500 Kbps
DN-02 MAC ID
Range:
Function:
63. N/A*
[0 - 63. N/A]
Selection of station address. Every station connected to the same DeviceNet network must have an
unambiguous address.
DN-05 Readout Transmit Error Counter
Range:
Function:
0 N/A*
[0 - 255 N/A]
View the number of CAN control transmission errors since the last power-up.
DN-06 Readout Receive Error Counter
Range:
Function:
0 N/A*
[0 - 255 N/A]
View the number of CAN control receipt errors since the last power-up.
DN-07 Readout Bus Off Counter
Range:
Function:
0 N/A*
[0 - 255 N/A]
View the number of network Off events since the last power-up.
DN-10 Process Data Type Selection
Option:
Function:
Select the Instance (message) for data transmission. The Instances available are dependent upon the
setting of par. O-10 Control Word Profile.
When par. O-10 Control Word Profile is set to [0] Drive protocol, par. DN-10 Process Data Type Selection
options [0] and [1] are available.
When par. O-10 Control Word Profile is set to [5] ODVA, par. DN-10 Process Data Type Selection options
[2] and [3] are available.
Instances 100/150 and 101/151 are GE-specific. Instances 20/70 and 21/71 are ODVA-specific AC Drive
profiles.
For guidelines in message selection, please refer to the DeviceNet Operating Instructions.
Note that a change to this parameter will be executed immediately.
[0] *
INSTANCE 100/150
[1]
INSTANCE 101/151
[2]
INSTANCE 20/70
[3]
INSTANCE 21/71
DN-11 Process Data Config Write
Select the process write data for I/O Assembly Instances 101/151. Elements [2] and [3] of this array can be selected. Elements [0] and [1] of the array are fixed.
Option:
Function:
Select the process write data for I/O Assembly Instances 101/151. Elements [2] and [3] of this array can be selected. Elements [0] and [1] of the array are fixed.
