2 alarm/warning limits, 1 warnings and alarm messages, 2 warnings – GE Industrial Solutions AF-650 GP DeviceNet User Manual
Page 56: 3 alarms

AF-650 GP or AF-600 FP
Bit (Hex)
Warning word (par. DR-92 Warning Word)
Warning no.
00000001
Unused
-
00000002
Drive over temperature
29
00000004
Earth fault
14
00000008
Unused
-
00000010
Control word timeout
18
00000020
Over current
13
00000040
Torque limit
12
00000080
Motor thermistor over temp.
11
00000100
Motor Thermal Electronic Overload over temperature
10
00000200
Drive overloaded
9
00000400
DC link under voltage
8
00000800
DC link over voltage
7
00001000
DC link voltage low
6
00002000
DC link voltage high
5
00004000
Mains phase loss
4
00008000
No motor
3
00010000
Live zero error
2
00020000
10 V low
1
00040000
Brake resistor power limit
26
00080000
Brake resistor short circuit
25
00100000
Brake chopper fault
27
00200000
Speed limit
49
00400000
Network comm. fault
34
00800000
24 V supply fault
47
01000000
Mains failure
36
02000000
Current limit
59
04000000
Unused
-
08000000
Unused
-
10000000
Unused
-
20000000
Unused
-
40000000
Unused
-
80000000
Warning word 2 (ext. stat. word)
-
8.2 Alarm/Warning Limits
8.2.1 Warnings and Alarm Messages
There is a clear distinction between alarms and warnings. In the event of an alarm, The frequency converter will enter a fault condition. After the cause for the
alarm has been cleared, the master will have to acknowledge the alarm message for the frequency converter to start operating again. A warning on the other
hand may come when a warning condition appears, and disappear when conditions return to normal without interfering with the process.
8.2.2 Warnings
All warnings within the frequency converter are represented by a single bit within a warning word. A warning word is always an action parameter. Bit status FALSE
[0] means no warning, while bit status TRUE [1] means warning. To each bit and each bit status there is a corresponding text string. In addition to the warning
word message the master will also be notified through a change of bit 7 in the Status Word.
8.2.3 Alarms
Following an Alarm message, the frequency converter will enter Fault condition. Only after the fault has been alleviated and the master has acknowledged the
alarm message by setting bit 3 in the Control Word, can the frequency converter resume operation. All alarms within the frequency converter are represented by
a single bit within an alarm word. An alarm word is always an action parameter. Bit status FALSE [0] means no alarm, while bit status TRUE [1] means alarm.
