5.3.3 Class ID 0x01
Attribute Access Name Data type Min/Max Units Default Description
1 Get Vendor USINT 97 Vendor Code
2 Get Device Type UNIT 2 AD/DC Motor
3 Get Product Code UNIT 100 See EDS File Section
4 Get Revision UNIT Software version on AF-600
FP or AF-650 GP
5 Get Status UNIT
6 Get Serial Number UDINT From frequency converter
7 Get Product Name String AF-600 FP or AF-650 GP
10 Get/Set Heartbeat Interval USINT 0-255 sec 0 Off
5.3.4 Class ID 03h DeviceNet Object
This is a standard DeviceNet Object for configuration and status of the DeviceNet connection.
The attributes supported for this class are listed below.
5.3.5 Class ID 0x03
Attribute Access Name Data type Min/Max Units Default Description
1 Get/Set MAC ID USINT 0-63 63 Node address
2 Get/Set Baud Rate USINT 0-2 0 0=125
1=250
2=500
4 Get BOC Bus-Off Counter
5 Get Allocate informa-
tion Only required if predefined
Master/Slave is implemented
6 Get MAC ID Switch
changed BOOL 0-1 0 The node address switch has
changed since the last pow-
er-up/reset
7 Get Baud rate switch-
ed from last power
up BOOL 0-1 0 The baud rate switch has
changed since the last pow-
er-up
5.3.6 Class ID 04h Assembly Object
This is a standard DeviceNet Object for transfer of the I/O Instances (Process Data) described in the section “How to control the Frequency Converter”. Using this
it is possible to send or read any of the defined Instances, either by polling or explicit messaging.
The attributes supported for this class are listed below.
5.3.7 Class ID 0x04
Attribute Access Name Data type Min/Max Units Default Description
3 Set Data ARRAY
