Receiver Description
Figure 8. Typical Expected Currents in Rx Mode
Supply Current - Rx Mode
26.00
28.00
30.00
32.00
2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25
Vsupply (V)
Is
upply
(
m
A
)
868 or
915 MHz
433 MHz
Detailed Current - Rx Mode
0.00
2.00
4.00
6.00
8.00
10.00
2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25
Vsupply (V)
Su
p
p
ly
C
u
rr
e
n
ts
(m
A
)
EVCC2
EVCC1
RXVCC
CVCC2
CVCC1
AVCC
DIVCC
IF2VCC
TXVCC
