Wake-up Control Register
Register reset value = (7f8be110)
16
Table 13. DTR Detailed Description
Name
Number
of bits Comments
DSOFFSET 4 Data Slicer reference tuning
(0000)
2
to (1111)
2
reset value: (1000)
2
DISCHIGH 1 Discriminator offset shift (high)
0: no shift
1: output level increased
reset value: 0
DISCLOW 1 Discriminator offset shift (low)
0: no shift
1: output level decreased
reset value: 0
Table 14. WUC Overview
Name WUE DATA STOP DATL ADD – WPER WL1
nbit 31 30 29 28-24 23 22 21-13 12-6
init 0 1 1 (11111)
2
1 0 (001011111)
2
(0000100)
2
Name WL2 ISTU – –
nbit 5-3 2 1 0
init (010)
2
0 0 0
Table 15. WUC Detailed Description
Name
Number
of bits Comments
WUE 1 Wake-up function enable
Returns to “0” when a valid message is received.
0: wake-up disable
1: wake-up enable
reset value: 0
DATA 1 Data content
0: message without data field
1: message with data field
reset value: 1
STOP 1 STOP field usage
0: fixed data length: data length set from 1 to 32 by DATL
1: variable data length: data length given by the STOP field location; DATL must be set to (11111)
2
reset value: 1
