62
ATA5811/ATA5812 [Preliminary]
4689B–RKE–04/04
Absolute Maximum Ratings
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating
only and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
Parameters Symbol Min. Max. Unit
Junction temperature T
j
150 °C
Storage temperature T
stg
-55 +125 °C
Ambient temperature T
amb
-40 +105 °C
Supply voltage VS2 V
MaxVS2
-0.3 +7.2 V
Supply voltage VS1 V
MaxVS1
-0.3 +4 V
Supply voltage VAUX V
MaxVAUX
-0.3 +7.2 V
Supply voltage VSINT V
MaxVSINT
-0.3 +5.5 V
ESD (Human Body Model ESD S 5.1)
every pin
HBM -2 +2 kV
ESD (Machine Model JEDEC A115A)
every pin
MM -200 +200 V
Maximum input level, input matched to 50
Ω
P
in_max
10 dBm
Thermal Resistance
Parameters Symbol Value Unit
Junction ambient R
thJA
25 K/W
