Figure 51. TX Transparent Mode (T_MODE = 1)
Write Control Register 4
XLim:
Don't care
ASK/_NFSK: Select modulation
Sleep0 ... Sleep4: Don't care
XSleep: Don't care
Write Control Register 3
FR7, FR8:
Adjust f
RF
VSOUT_EN: Set VSOUT_EN = 1
CLK_ON: Don't care
Write Control Register 2
FR0 ...FR6:
P_mode:
Don't care
Write Control Register 1
IR1, IR0:
Don't care
AVCC_EN: Don't care
FS: Select operating frequency
OPM1, OPM0: Set OPM1 = 0 and OPM0 = 1
T_mode: Set T_mode = 1
Write Control Register 1
OPM1, OPM0:
Set IDLE (OPM1=0, OPM0=0)
Idle Mode
Start-up
Mode (TX)
T
Startup
= 331,5 × T
DCLK
TX Mode
Idle Mode
Apply TX Data on Pin SDI_TMDI
Adjust f
RF
