Control Register 3 (ADR 2)
Control Register 4 (ADR 3)
Table 23. Control Register 3 (Function of Bit 3 and Bit 2)
FR8 FR7 Function
0 0 FREQ3 = 0
0 1 FREQ3 = 128
1 0 FREQ3 = 256 (default)
1 1 FREQ3 = 384
Note: Tuning of f
RF
MSB’s
Table 24. Control Register 3 (Function of Bit 1)
VSOUT_EN Function
0 Output voltage power supply for external devices off (pin VSOUT)
1 Output voltage power supply for external devices on (default)
Note: This bit is set to 1 if the Bit-check is ok (RX_Polling, RX mode), an event at pin T1, T2,
T3, T4 or T5 occurs or the bit Power_On in the status register is 1.
Setting VSOUT_EN = 0 in AUX mode is not allowed
Table 25. Control Register 3 (Function of Bit 0)
CLK_ON Function
0 Clock output off (pin CLK)
1 Clock output on (default)
Note: This bit is set to 1 if the Bit-check is ok (RX_Polling, RX mode), an event at pin T1, T2,
T3, T4 or T5 occurs or the bit Power_On in the status register is 1.
Table 26. Control Register 4 (Function of Bit 7)
ASK_NFSK Function
0 FSK mode (default)
1 ASK mode
Table 27. Control Register 4 (Function of Bit 6, Bit 5, Bit 4, Bit 3 and Bit 2)
Sleep4 Sleep3 Sleep2 Sleep1 Sleep0
Function Sleep
(T
Sleep
= Sleep
Ч
1024
Ч
T
DCLK
×
X
Sleep
)
0 0 0 0 0 0
0 0 0 0 1 1
. . . . .
0 1 0 1 0
10
(T
Sleep
= 10
Ч
1024
Ч
T
DCLK
×
X
Sleep
)
(default)
. . . . .
1 1 1 1 1 31
