30
ATA5811/ATA5812 [Preliminary]
4689B–RKE–04/04
If V
VSOUT
drops below V
Thres_1
(typically 2.3 V), N_RESET is set to low. If bit VSOUT_EN
in control register 3 is 1, a DVCC_RESET is also generated. If V
VSOUT
was prior dis-
a b l e d b y t h e c o n n e c t e d m i c r o c o n t ro l l e r b y s e t t i n g b i t V S OU T _ E N = 0 , n o
DVCC_RESET is generated.
Note: If VSOUT < V
Thres_1
(typically 2.3 V) the output of the pin CLK is low, the
Microcontroller_Interface is disabled and the transceiver is not programmable via the
4-wire serial interface.
Figure 23. Reset Timing
VSOUT
DVCC
(AVCC)
DVCC_RESET
V
Thres_1
= 2.3 V (typ)
N_RESET
Low_Batt
(Status Register)
VSOUT_EN
(Control Register 3)
1.5 V (typically)
CLK
V
VSOUT
> 2.3 V and the XTO is running
V
VSOUT
> 2.38 V and the XTO is running
V
Thres_2
= 2.38 V (typ)
