6.4.12 LCD Drivers
Table 107: LCD Driver Performance Specifications
PARAMETER CONDITION MIN TYP MAX UNIT
VLCD Current VLCD=3.3, all LCD map bits=0
VLCD=5.0, all LCD map bits=0 2
3 uA
uA
Note:
1. These specifications apply to all COM and SEG pins.
2. VLCD = 2.5 V to 5 V.
3. LCD_VMODE=3, LCD_ON=1, LCD_BLANK=0, LCD_MODE=6, LCD_CLK=2.
4. Output load is 74 pF per SEG and COM pin.
