Name
Location
Rst Wk Dir Description
TEMP_22[10:8]
TEMP_22[7:0]
230A[2:0]
230B[7:0]
0 –
R
Storage location for STEMP at 22C. STEMP is an 11-bit word.
TEMP_BAT
28A0[4]
0 – R/W
Causes VBAT to be measured whenever a temperature measurement is
performed.
TEMP_BSEL
28A0[7]
0 – R/W
Selects which battery is monitored by the temperature sensor: 1 = VBAT,
0 = VBAT_RTC
TBYTE_BUSY
28A0[3]
0 0
R
Indicates that hardware is still writing the 0x28A0 byte. Additional writes to
this byte will be locked out while it is one. Write duration could be as long as
6ms.
TEMP_PER[2:0]
28A0[2:0]
0 – R/W
Sets the period between temperature measurements. Automatic measurements
can be enabled in any mode (MSN, BRN, LCD, or SLP). TEMP_PER = 0
disables automatic temperature updates, in which case TEMP_START may be
used by the MPU to initiate a one-shot temperature measurement.
TEMP_PER
Time (seconds)
0
No temperature updates
1-6
2
(3+TEMP_PER)
7
Continuous updates
TEMP_PWR
28A0[6]
0 – R/W
Selects the power source for the temp sensor:
1 = V3P3D, 0 = VBAT_RTC. This bit is ignored in SLP and LCD modes,
where the temp sensor is always powered by VBAT_RTC.
TEMP_START
28B4[6]
0 0 R/W
When TEMP_PER = 0 automatic temperature measurements are disabled,
and TEMP_START may be set by the MPU to initiate a one-shot temperature
measurement. TEMP_START is ignored in SLP and LCD modes. Hardware
clears TEMP_START when the temperature measurement is complete.
TMUX[5:0]
2502[5:0]
– – R/W Selects one of 32 signals for TMUXOUT. See
TMUX2[4:0]
2503[4:0]
– – R/W Selects one of 32 signals for TMUX2OUT. See
TMUXRA[2:0]
270A[2:0]
000 000 R/W The TMUX setting for the remote isolated sensor (71M6x01).
VERSION[7:0]
2706[7:0]
– –
R
The silicon version index. This word may be read by firmware to determine
the silicon version.
VERSION[7:0] Silicon Version
0001 0011
0010 0010
B01
B02
VREF_CAL
2704[7]
0 0 R/W
Brings the ADC reference voltage out to the VREF pin. This feature is disabled
when VREF_DIS=1.
VREF_DIS
2704[6]
0 1 R/W Disables the internal ADC voltage reference.
