138 © 2008–2011 Teridian Semiconductor Corporation v1.1
6 Electrical Specifications
This section provides the electrical specifications for the 71M654x. Please refer to the 71M6xxx Data
Sheet for the 71M6x01 electrical specifications, pin-out and package mechanical data.
6.1 Absolute Maximum Ratings
Table 93 shows the absolute maximum ratings for the device. Stresses beyond Absolute Maximum Ratings
may cause permanent damage to the device. These are stress ratings only and functional operation at
these or any other conditions beyond those indicated under recommended operating conditions (see
6.3
Recommended Operating Conditions ) is not implied. Exposure to absolute-maximum-rated conditions
for extended periods may affect device reliability. All voltages are with respect to GNDA.
Table 93: Absolute Maximum Ratings
Voltage and Current
Supplies and Ground Pins
V3P3SYS, V3P3A
−0.5 V to 4.6 V
VBAT, VBAT_RTC -0.5 V to 4.6 V
GNDD -0.1 V to +0.1 V
Analog Output Pins
VREF
-10 mA to +10 mA,
-0.5 V to V3P3A+0.5 V
VDD
-10 mA to 10 mA,
-0.5 to 3.0 V
V3P3D
-10 mA to 10 mA,
-0.5 V to 4.6 V
VLCD
-10 mA to 10 mA,
-0.5 V to 6 V
Analog Input Pins
IAP-IAN, VA, IBP-IBN, VB
†
(
†
71M6542F only)
-10 mA to +10 mA
-0.5 V to V3P3A+0.5 V
XIN, XOUT
-10 mA to +10 mA
-0.5 V to 3.0 V
SEG and SEGDIO Pins
Configured as SEG or COM drivers
-1 mA to 1 mA,
-0.5 V to VLCD+0.5 V
Configured as Digital Inputs
-10 mA to 10 mA,
-0.5 V to 6 V
Configured as Digital Outputs
-10 mA to 10 mA,
-0.5 V to V3P3D+0.5 V
Digital Pins
Inputs (PB, RESET, RX, ICE_E, TEST)
-10 mA to 10 mA,
-0.5 to 6 V
Outputs (TX)
-10 mA to 10 mA,
-0.5 V to V3P3D+0.5 V
Temperature and ESD Stress
Operating junction temperature (peak, 100ms) 140 °C
Operating junction temperature (continuous) 125 °C
Storage temperature −45 °C to +165 °C
Solder temperature – 10 second duration 250 °C
ESD stress on all pins 4 kV
