Rev.A - May 17, 2001 99
Preliminary
T89C51CC02
CANTCON (S:A1h)
CAN Timer ClockControl
Reset Value: 00h
Figure 97. CANTCON Register
CANTIMH (S:ADh Read Only)
CAN Timer High
Reset Value: 0000 0000b
Figure 98. CANTIMH Register
CANTIML (S:ACh Read Only)
CAN Timer Low
Reset Value: 0000 0000b
Figure 99. CANTIML Register
7 6 5 4 3 2 1 0
TPRESC 7 TPRESC 6 TPRESC 5 TPRESC 4 TPRESC 3 TPRESC 2 TPRESC 1 TPRESC 0
Bit Number Bit Mnemonic Description
7-0 TPRESC7:0
Timer Prescaler of CAN Timer
This register is a prescaler for the main timer upper counter
range = 0 to 255.
See Figure 63.
7 6 5 4 3 2 1 0
CANGTIM 15 CANGTIM 14 CANGTIM 13 CANGTIM 12 CANGTIM 11 CANGTIM 10 CANGTIM 9 CANGTIM 8
Bit Number Bit Mnemonic Description
7-0 CANGTIM15:8
High byte of Message Timer
See Figure 63.
7 6 5 4 3 2 1 0
CANGTIM 7 CANGTIM 6 CANGTIM 5 CANGTIM 4 CANGTIM 3 CANGTIM 2 CANGTIM 1 CANGTIM 0
Bit Number Bit Mnemonic Description
7-0 CANGTIM7:0
Low byte of Message Timer
See Figure 63.
