16.7. PCA Registers
CMOD (S:D8h)
PCA Counter Mode Register
Reset Value = 00XX X000b
Figure 110. CMOD Register
7 6 5 4 3 2 1 0
CIDL WDTE - - - CPS1 CPS0 ECF
Bit Number Bit Mnemonic Description
7 CIDL
PCA Counter Idle Control bit
Clear to let the PCA run during Idle mode.
Set to stop the PCA when Idle mode is invoked.
6 WDTE
Watchdog Timer Enable
Clear to disable Watchdog Timer function on PCA Module 4,
Set to enable it.
5 -
Reserved
The value read from this bit is indeterminate. Do not set this bit.
4 -
Reserved
The value read from this bit is indeterminate. Do not set this bit.
3 -
Reserved
The value read from this bit is indeterminate. Do not set this bit.
2 CPS1
EWC Count Pulse Select bits
CPS1 CPS0 Clock source
0 0 Internal Clock, FPca/6
0 1 Internal Clock, FPca/2
1 0 Timer 0 overflow
1 1 External clock at ECI/P1.2 pin (Max. Rate = FPca/4)
1 CPS0
0 ECF
Enable PCA Counter Overflow Interrupt bit
Clear to disable CF bit in CCON register to generate an interrupt.
Set to enable CF bit in CCON register to generate an interrupt.
