SADEN (S:B9h)
Slave Address Mask Register

Reset Value = 0000 0000b
Not bit addressable

Figure 30. SADEN Register

SADDR (S:A9h)
Slave Address Register

Reset Value = 0000 0000b
Not bit addressable

Figure 31. SADDR Register

SBUF (S:99h)
Serial Data Buffer

Reset Value = 0000 0000b
Not bit addressable

Figure 32. SBUF Register

7

6

5

4

3

2

1

0

Bit Number Bit Mnemonic

Description

7-0

Mask Data for Slave Individual Address

7

6

5

4

3

2

1

0

Bit Number Bit Mnemonic

Description

7-0

Slave Individual Address

7

6

5

4

3

2

1

0

Bit Number Bit Mnemonic

Description

7-0

Data sent/received by Serial I/O Port
