100 Rev.A - May 17, 2001
Preliminary
T89C51CC02
CANSTMPH (S:AFh Read Only)
CAN Stamp Timer High
No default value after reset
Figure 100. CANSTMPH Register
CANSTMPL (S:AEh Read Only)
CAN Stamp Timer Low
No default value after reset
Figure 101. CANSTMPL Register
CANTTCH (S:A5h Read Only)
CAN TTC Timer High
Reset Value: 0000 0000b
Figure 102. CANTTCH Register
7 6 5 4 3 2 1 0
TIMSTMP 15 TIMSTMP 14 TIMSTMP 13 TIMSTMP 12 TIMSTMP 11 TIMSTMP 10 TIMSTMP 9 TIMSTMP 8
Bit Number Bit Mnemonic Description
7-0 TIMSTMP15:8
High byte of Time Stamp
See Figure 63.
7 6 5 4 3 2 1 0
TIMSTMP 7 TIMSTMP 6 TIMSTMP 5 TIMSTMP 4 TIMSTMP 3 TIMSTMP 2 TIMSTMP 1 TIMSTMP 0
Bit Number Bit Mnemonic Description
7-0 TIMSTMP7:0
Low byte of Time Stamp
See Figure 63.
7 6 5 4 3 2 1 0
TIMTTC 15 TIMTTC 14 TIMTTC 13 TIMTTC 12 TIMTTC 11 TIMTTC 10 TIMTTC 9 TIMTTC 8
Bit Number Bit Mnemonic Description
7-0 TIMTTC15:8
High byte of TTC Timer
See Figure 63.
