T89C51CC02
CH (S:F9h)
PCA Counter Register High value
Reset Value = 0000 00000b
Figure 115. CH Register
CL (S:E9h)
PCA counter Register Low value
Reset Value = 0000 00000b
Figure 116. CL Register
7 6 5 4 3 2 1 0
CH 7 CH 6 CH 5 CH 4 CH 3 CH 2 CH 1 CH 0
Bit Number Bit Mnemonic Description
7:0 CH 7:0 High byte of Timer/Counter
7 6 5 4 3 2 1 0
CL 7 CL 6 CL 5 CL 4 CL 3 CL 2 CL 1 CL 0
Bit Number Bit Mnemonic Description
7:0 CL0 7:0 Low byte of Timer/Counter
