Variations, Figure 5, Gas flow pattern of available probe variants – M&C TechGroup SP2000H_DIL_BR Operator's manual User Manual
Page 12
12
Gas sampling and gas conditioning technology
2-1.1.7-ME
7.1
VARIATIONS
The gas flow patterns of the available probe variants are shown in the following figure.
SP2000-H/DIL
SP2000-H320/DIL
Dilution gas
measuring point
sample gas out
Underpressure
180° C
Test gas
Underpressure
measuring point
Test gas
320°C
Dilution gas
sample gas out
SP2000-H/DIL-VA
SP2000-H/DIL-VA-B
SP2000-H/DIL-B* (-BR*)
180° C
Test gas Dilution gas
measuring point
Sample gas out
Underpressure
not present
with type *
-B
-BR
Bypass gas in
*
Sample gas
Dilution gas
Underpressure
measuring point
180°C
Sample gas out
SP2000-H/DIL-VA-BV
Underpressure
measuring point
Sample gas
180°C
Dilution gas
Sample gas out
Bypassgas out
Figure 5
Gas flow pattern of available probe variants
