Gas sampling and gas conditioning technology 4-1.1-ME
7 TECHNICAL DATA
Gas flow rate** CSS(/C) : max. 140l/h
CSS-2 : max. 2 x 140l/h
CSS-3(/C) : max. 350l/h
Flow meter CSS(/C), CSS-2: 2 x with needle valve, adjustable to 70l/h,
flow meter FM1 with flow alarm sensor
CSS-3(/C) : 2 x with needle valve, adjustable to 250l/h,
flow meter FM1 with flow alarm sensor
Gas pressure 0,7bar to 1,4bar abs.
Sample inlet temperature** max. 150°C
Sample inlet dew point** max. 80°C
Sample outlet dew point range of adjustment: +2 °C ..... +15 °C, factory setting: +5 °C
Dew point stability at constant conditions < ± 0,1 °C
Gas filter F-0,1GF50 Glass fiber, retention rate 99,99% for particles > 0,1µm
Ambient temperature** +5°C to +45°C
Storage temperature -25°C to +65°C
Relative humidity < 80%
Housing 19"-rack housing mounting 6 U, depth 350mm
Degree of protection IP20, DIN40050
Weight CSS(/C) : approx. 15kg
CSS-2, CSS-3(/C): approx. 16,5kg
Connections G 1/4 i* - DIN ISO 228/1
Power supply 230V 50/60Hz or 115V 60Hz, CSS : 150VA
CSS-2/3: 250VA
Electrical connection Power terminals max. 4 mm 2 (4 x PG 13,5)
Alarm-/Control signal 15 pin Sub-D-Connector
Warm up time approx. 10 min.
Material of sample contacting
parts PVDF, glass, Viton

, Novoprene

, PTFE
Status signal for Measure/Check, cooler temperature, liquid alarm, flow alarm:
potential free change over contact, max. 24V/1A
Test gas inlet - 2 x solenoid valve actuated by manual or external switch
Option:
Electronic PID temperature con-
troller for heated sample lines
front panel mounting
control range : 0°C to 200°C
sensor inlet : PT 100 and Fe-CuNi
controlling outlet : 10A solid state relay
#
status alarm : integrated into the status signal
parameter : free adjustable
Electrical equipment standard EN 60204-1 (DIN VDE 0113 Teil 1/02.86)
* other connections on request
** Maximum values in technical datas must be rated in consideration of total cooling capacity at 25 °C ambient temperature and an outlet dew
point of 5 °C.
# standard for max. 20m heated sample line at 110W/m
