36
Gas sampling and gas conditioning technology 4-1.1-ME
22 SPARE PART LISTS
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
19“ GAS CONDITIONING UNIT TYPE CSS...
(C) consumable parts, (R) recommended spare parts, (S) spare parts
recommended quantity
in operation [years]
Artikel-Nr. Bezeichnung C/R/S 1 2 3
Cooler ECP-1000/ECP-2000, ECP-3000: 10 (s. Fig.4)
93 K 1030 Jet-Stream heat exchanger ECP-1000/2000G 90° R 0 1 1
93 K 0150 Jet-Stream heat exchanger ECP-3000G 90° R 0 1 1
90 K 0115 Thermal conductivity paste, 50g R 1 1 2
93 K 0020 Power supply board compl. for ECP1000-3000 R - 1 1
93 K 0530 ECP-1000 Netzteilplatine kompl. R - - 1
93 K 0030 Fine fuse 0,8AT 5x20 ECP-1000 R 2 4 4
93 K 0540 Fuse 5 X 20, 1,6 AT for ECP-2000/3000 R 2 4 4
93 K 0010 ECP-1000 fan 12V DC C - - 1
93 K 0036 Diode ECP-1000 R - - 1
90 K 2010 Rectifier for cooler type ECP1000-3000 R - - 1
90 K 2020 Power transistor BUZ11 for ECP1000-3000 R - - 1
93 K 0040 PT-100 temperature sensor R - - 1
93 K 0045 ECP-1000 peltier element 4/4 R - - 1
93 K 0520 ECP-2000/3000 peltier element 6/6 R - - 1
90 K 0145 ECP-alarm relay DSP1 R - - 1
Peristaltic pump SR25: 1.2.2 (s. Fig.3)
90 P 1007 SR25 pump hose with PVDF tube connectors DN
4/6mm C 1 2 4
90 P 1020 Driver complete for peristaltic pump SR25.1 S - 1 1
90 P 1010 Set contact spring for SR25.1 (4 pcs.) R 1 2 2
90 P 1045 Contact pulley(1 pc.) for (2 pcs./pump required) S 2 4 4
90 P 1050 Conveying belt for SR25 S - 1 2
90 P 1025 S-bolt S - - 1
01 P 1000 Peristaltic pump complete, 230/115V 50/60Hz R - - 1
3-Way solenoid valve: 14 (s. Fig.4)
90 K 6040 3-Way solenoid valve, 230V f. CSS(/C)/CSS-3(/C) S - - 1
90 K 6041 3-Way solenoid valve, 115V f. CSS(/C)/CSS-3(/C) S - - 1
2-Way solenoid valve: 16 (s. Fig.4)
90 G 3000 2/2-way solenoid valve 6011 for CSS 230V 50Hz
for CSS(/C) and CSS-3(/C)
S - - 1
90 G 3005 2/2-way solenoid valve 6011 for CSS, 115V
for CSS(/C) and CSS-3(/C)
S - - 1
Universal filter FPF-0,1: 1.2.1 (s. Fig.3)
90 F 0009 Filter element type F-0,1GF50 0,1µm R 4 8 12
90 F 0118 Filter glass F-45 R 1 2 2
90 F 0044 Viton-O-ring, 35 for FPF-0,1 R 1 2 2
90 F 0095 PVDF filter ement clamp FPF-GF
S - 1 1
