28
Gas sampling and gas conditioning technology 4-1.1-ME
16 SUPPLY CONNECTIONS
16.1 HOSE CONNECTION
N O T E !
The CSS is equipped with G1/4“i connections.
Do not mix up the hose connections: they are clearly marked. Af-
ter all the hoses have been connected, the tightness of such leads
should be checked.
Connection hoses with dimensions DN 4/6mm are utilised for all models.
The following lines have to be connected (Fig. 5):

sample gas line to connection (C) respectively to connection (M), operating with version CSS-2
(second independent gas flow);

zero gas line to connection (F);

span gas line to connection (G);

line -test gas to sample gas probe (CSS.../C)- to connection (I);

analyser(s) to outlets (D) and (E); maximum two sample gas outlets are available; with version
CSS-2 an additional sample gas outlet (K) is available;

connect the condensate hose to the outlet (H) respectively to the outlet (L), operating with version
CSS-2 ( second independent gas flow); the hose must be laid with slope to a ventilated sewer or
reservoir; it is absolutely necessary to install the ventilation outside the analysers cabinet and ana-
lysers house;
N O T E !
The tightness of the connections can only be guaranteed if the
connecting hose has a straight rim (hose cutter).
W A R N I N G !
Aggressive condensate is possible. Wear protective glasses and
proper protective clothing!
16.2 ELECTRICAL CONNECTIONS
W A R N I N G !
False supply voltage can demage the equipment. When connect-
ing the equipment, please ensure that the supply voltage is iden-
tical with the information provided on the model type plate!
