2.4.3. Recorder Status Panel
Overview of the Recorder Status Panel
Depending on the EVS server configurations, up to 6 recorder channels can be displayed
per server.
The Recorder Status panel provides the following information for each recorder channel
displayed on the panel:
• recorder channel name
• remaining capacity on the recorder
• recording status
◦ capacity information on a red background if the channel is recording
◦ capacity information on a gray background if the channel is not recording
• Lock icon next to the remaining capacity information, if the channel is
locked
• Gang Group icon next to the remaining capacity information, if the channel is
part of a gang group.
Recorder Status Tab Contextual Menu
A contextual menu appears when you right-click the Recorder Status tab.
The following table describes the commands available from the contextual menu.
Menu Item Description
View
Recorders Expands the Recorder Status panel and displays the list of recorder
channels as selected from the Define the Recorder Channels
window.
Add/Remove
Recorders Allows the user to add recorders to or remove recorders from the
Recorder panel.
Selecting this item opens the Define the Recorder Channels
window from which you can select the recorders to be added to or
removed from the Recorder Status panel.
View All
Recorders Expands the Recorder Status panel and displays all recorder
channels available on the XNet network.
Recorder Channel Contextual Menu
A contextual menu appears when you right-click a recorder area.
The following table describes the commands available from the contextual menu.
