The Output GPIs are used to send a signal from the IPDirector to a GPI key at a given
timecode of a playlist played on a given player channel. This signal can then be used to
trigger a record action of the playlist from the given timecode by a third device, for
example a VTR. Up to eight Output GPI commands can be defined.
The Output GPI keys will be unavailable in IPDirector if they have been assigned to the
Remote panel via the Replace function defined on the Remote panel itself.
For each Output GPI, the output mode, the pulse duration and the offset value can be set
when defining the Output GPI. For more detailed information, refer to
the Playlist Panel
user manual .
The Output GPIs Settings window is used to determine how to use the TTL GPIs and to
specify the Advance value.
Advance
In the Advance field, you can specify how many seconds ahead of the timecode (on
which the GPI tag is defined) the Output GPI signal should be sent by the IPDirector.
6.6. OSD Settings
6.6.1. Overview
The On-Screen Display settings allow the users to select the category of information to be
displayed for each playout channel. This does not apply to recorder channels or software
player.
