the player channel controlled by the remote must be assigned to the playlist panel or
the control panel where the playlist is opened.

How to Browse a Playlist

To browse a playlist when the prerequisites are met, proceed as follows:

1. Press the BROWSE button on the remote.

The panel on which the playlist is opened becomes active on screen.

2. Use the wheel to select a playlist element:

in clockwise to select the next element

in a counter-clockwise to select the previous element.

The selected element is cued on its IN point.

Browsing Clips

Prerequisites

To be able to browse a clip with the remote, some conditions must be met:

a player channel or the Software player must be controlled by the remote

the player channel or Software player controlled by the remote must be assigned to
the Database Explorer

the remote must be linked to the Database Explorer by double-clicking the BEPlay
Remote area on the status bar of the Database Explorer.

Moving through the Database Explorer

The users can navigate in the grid, in the tree view or in the saved filters pane if it is
displayed. To move from one pane of the Database Explorer to another, use the following
remote buttons:

NEXT: move from grid → saved filters, if the pane is displayed → tree view

PREV: move from grid → tree view → saved filters, if the pane is displayed.

Note
The active pane is not highlighted. When you turn the remote wheel, you will see
in which pane the selection is moving.

How to Browse a Clip in the Grid

To browse clips when the prerequisites are met, proceed as follows:

1. Press the BROWSE button on the remote.

The Database Explorer linked to the remote becomes active on screen.

The Browse mode of the Database Explorer is enabled

The focus is on the grid.

2. Use the wheel to select a clip:
