EVS IPDirector Version 6.2 - June 2013 GENERAL FUNCTIONS User Manual - Manual (Page 164)

Playlist 1
(PL1)
Playlist 2 (PL2)
Normal Fill Key
Key Normal PL2 → Fill
Link the two PL If Fill not yet linked:
Link the two PL Invalid operation
Error message in the
error list
If Fill already linked:
Error message in
popup window
When a Fill and Key association already exists, a warning message will be displayed
informing you that the playlist must first be unlinked to be able to create a new
association. For example:
How to Manually Unlink Two Fill and Key Playlists
To manually remove the link between one or several Fill playlists and one or several Key
playlists, proceed as follows:
1. In the Database Explorer, select either one playlist of the Fill and Key association or
both.
You can also select playlists from multiple associations.
2. Right-click one of the selected playlist.
The Playlist contextual menu opens.
3. Select Unlink from the menu.
All Fill and Key associations of all elements from the selection are cleared, but the type of
each playlist is kept.
Opening and Loading a Fill or Key Playlist
General procedures for the opening of a Normal playlist and for the loading of a Normal
playlist on a player channel are detailed in
the Playlist Panel user manual .
However, the behavior of the system could be slightly different when you work with Fill or
Key playlists as well as when you try to load a Normal playlist on a Fill or Key channel.
The table below describes the different actions which result when
• you want to open a Normal, Fill or Key playlist in a Playlist Panel or the clip-list tab of a
Control Panel (no channel associated)
152 11. Fill and Key
EVS Broadcast Equipment S.A. - June 2013 Issue 6.2.A
