Element
Type

Playlist Type

Fill

Key

Key

Error message: you cannot insert a Key
element into a Fill PL

If Key element is not
linked to a Fill element:
Key Element inserted in
Key PL.

If Key element is linked to
a Fill element:

1. Key element inserted

in Key PL.

2. Corresponding Fill

element inserted in
corresponding Fill PL.

Note
When a Key clip is linked to several Fill clips, it cannot be inserted into a Key
playlist. You should insert the Fill clip into the fill playlist to avoid any confusion.

Warning
When the element is appended to the playlist, by using the APPEND CLIP
button or the Send to Default Playlist option, both Fill and Key elements will be
added at the last position in their respective playlist, even if the playlists do not
have the same number of elements.

Modifying an Element in a Fill or Key Playlist

When the user modifies one of the parameters listed below to a Fill (or Key) playlist
element, the modification is automatically applied to the corresponding Key (or Fill)
playlist element:

Playlist element duration

Playlist element name

Moving Fill and Key Playlist Elements

Moving a Fill (or Key) playlist can be done in the same way as for a Normal playlist.

The elements are moved inside the Fill (or Key) playlist as well as the corresponding
elements in the Key (or Fill) playlist which are moved at the same position.

Removing Playlist Elements from a Fill or Key
Playlist

Removing elements in a Fill (or Key) playlist can be done in the same way as for a Normal
playlist.

All selected elements in the Fill (or Key) playlist are removed as well as the corresponding
elements in the Key (or Fill) playlist.
