Action

Description

channel.

SKIP

Initiates a command to skip the clip being played on the selected
channel.

TALLY

Activates or deactivates the on-air flag on the selected channel.

EXITASAP

Initiates a command to exit the loop as soon as possible without playing
the current element until its end and jump to the selected element.

EXITOUT

Initiates a command to exit the loop as soon as the OUT point of the
current element is reached and jump to the selected element.

NONE

No value is defined.

Channel

The Channel field allows the user to define the channel on which the GPI key action will
be executed. The possible values are:

a channel of the EVS server to which the GPI is physically linked

the None value.

Trigger Mode

The Trigger Mode field allows the user to define the type of trigger signal that will be sent
by the GPI to the EVS server. The following trigger modes can be defined:

Trigger Mode

Description

Pulse Rising Edge

The trigger is done on a rising edge pulse.

Pulse Falling Edge

The trigger is done on a falling edge pulse.

Level High

The trigger is done when the level changes to high level.

Level Low

The trigger is done when the level changes to low level.

None

No trigger mode is defined.

Note
If the operator selects None for one of the fields, all three fields are reset to
None. It is considered that the GPI is not used.
