background image

Fatal1ty Z77 Professional Series Motherboard

9

English

- Pixel Shader 5.0, DirectX 11 with Intel

®

Ivy Bridge CPU.

Pixel Shader 4.1, DirectX 10.1 with Intel

®

Sandy Bridge

CPU.

- Max. shared memory 1760MB (see

CAUTION 5)

- Dual VGA Output: support HDMI and DisplayPort ports by

independent display controllers

- Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports DisplayPort with max. resolution up to 2560x1600

@ 60Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required) (see

CAUTION 6)

- Supports HDCP function with HDMI and DisplayPort ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with HDMI and DisplayPort ports

Audio

- 7.1 CH HD Audio with Content Protection

(Realtek ALC898 Audio Codec)

- Premium Blu-ray audio support

LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Broadcom BCM57781

- Supports Wake-On-LAN

- Supports Energy Efficient Ethernet 802.3az

- Supports Dual LAN with Teaming function

- Supports PXE

Rear Panel I/O

I/O Panel

- 1 x PS/2 Keyboard/Mouse Port

- 1 x HDMI Port

- 1 x DisplayPort

- 1 x Optical SPDIF Out Port

- 5 x Ready-to-Use USB 2.0 Ports

- 1 x Fatal1ty Mouse Port (USB 2.0)

- 1 x eSATA3 Connector

- 6 x Ready-to-Use USB 3.0 Ports

- 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED

LED)

- 1 x IEEE 1394 Port

- 1 x Clear CMOS Switch with LED

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone (see

CAUTION 7)
