5–7

Dialing Messages

Dialing will cause the following screen to be displayed on the LCD:

The dialed phone number will be displayed on the second line of the 20

2 LCD

screen. If the number exceeds 20 digits, only the first 20 digits/characters will be dis-
played. If the modem's DIAL-UP LINE jack is not plugged in or not connected, the
LCD screen will display the following:

then the modem will go back to the

IDLE STATUS screen. If the line is busy, after

three to five seconds, the LCD displays:

then goes back to the

IDLE STATUS screen. If the phone company is ringing the re-

mote modem, a

RINGING

message is sent to the terminal. Setting

S42.6 = 1

will disable this

RINGING

result code. If any key interruption occurs (from the ter-

minal or panel) and breaks in before the connection is made, the screen displays:

then goes back to the

IDLE STATUS screen. If the time interval depicted in the

then goes back to the

IDLE STATUS screen. If the first handshaking signal has been

detected, the LCD screen will display:

DIALING......................

1234567

NO DIAL TONE..........

1234567

BUSY..............................

1234567

ABORT...........................

1234567

DISCONNECTING.........

1234567

HANDSHAKING.............

1234567
