9–5
Examples:
X5:
CONNECT 38400/V.32 9600T/MNP5
CONNECT 115200/V.34 28800/V.42b
Error control level is from
NONE
to
V.42b
.
X6:
CONNECT 9600/ARQ
CONNECT 28800/ARQ
Error control level is either
ARQ
or not given at all.
X7:
CONNECT 9600/ARQ/MNP5
CONNECT 28800/ARQ/V.42b
Use
S35.7=1
to enable the following numerical result codes when
an error control connection is being made:
Z0
Reset modem and load user profile 0.
Z1
Reset modem and load user profile 1.
Z2
Reset modem and load user profile 2.
Z3
Reset modem and load user profile 3.
Z4
Resets the modem and loads the factory settings, also sets the factory
default as power-on profile.
*. Data compression included.
/SREJ
is appended if a V.42 connection with selec-
tive reject is established.
**. When more than one type of Distinctive Ring is turned on (
S40b3-6
),
RING n
will be reported, n=Ring type (1-4).
***. Use
S42b6
to disable
RINGING
result code.
ATVO
Code
ATV1
String
ATVO
Code
ATV1
String
50
CONNECT
58
CONNECT 16800
51
CONNECT 1200
59
CONNECT 19200
52
CONNECT 2400
60
CONNECT 21600
53
CONNECT 4800
61
CONNECT 24000
54
CONNECT 7200
62
CONNECT 26400
55
CONNECT 9600
63
CONNECT 28800
56
CONNECT 12000
64
CONNECT 31200
57
CONNECT 14400
65
CONNECT 33600
Note:
Factory default (
Z4
) is the default power-on profile when the
modem is shipped out of the factory.
ATZn
also sets profile n to be
the power-on profile.
ATZn
sets
FCLASS=0
.
