9–3
Q2 The modem returns a result code but quiet after answering on a
RING . (See also S42b2 )
Sr=n Sets S-register r to value n ; n must be a decimal number between 0
and 255.
Sr? Displays value stored in S-register r .
Sr.b=n Sets bit b of S-register r to value n . ( n is a binary digit: 0 or 1)
Sr.b? Display value of bit b of S-register r .
+ T Tone dial. (Default)
V0 Displays the result code in numeric form. (See also S35b7 and the
result code table of ATXn .)
+ V1 Display the result code in textual form. (Default)
Xn Result code and call progress monitor options (Default is X5 ):
Result Codes for
ATV0
ATV1
X0 X1 X2 X3 X4 X5 X6 X7
0 OK ● ● ● ● ● ● ● ●
1 CONNECT ● ● ● ● ● ✚ ✚ ✚
2 RING** ● ● ● ● ● ● ● ●
3 NO CARRIER ● ● ● ● ● ● ● ●
4 ERROR ● ● ● ● ● ● ● ●
5 CONNECT 1200 ● ● ● ● ✚ ✚ ✚
6 NO DIAL TONE ● ● ● ● ●
7 BUSY ● ● ● ● ●
8 NO ANSWER ● ● ● ● ●
9 RINGING*** ● ● ● ● ●
10 CONNECT 2400 ● ● ● ● ✚ ✚ ✚
11 CONNECT 4800 ● ● ● ● ✚ ✚ ✚
12 CONNECT 9600 ● ● ● ● ✚ ✚ ✚
14 CONNECT 19200 ● ● ● ● ✚ ✚ ✚
15 CONNECT 7200 ● ● ● ● ✚ ✚ ✚
16 CONNECT 12000 ● ● ● ● ✚ ✚ ✚
17 CONNECT 14400 ● ● ● ● ✚ ✚ ✚
18 CONNECT 16800 ● ● ● ● ✚ ✚ ✚
19 CONNECT 38400 ● ● ● ● ✚
20 CONNECT 57600 ● ● ● ● ✚
