9–4
21 CONNECT 76800 ● ● ● ● ✚
22 CONNECT 115200 ● ● ● ● ✚
23 CONNECT 230400 ● ● ● ● ✚
24 CONNECT 460800 ● ● ● ● ✚
25 CONNECT 921600 ● ● ● ● ✚
26 CONNECT 307200 ● ● ● ● ✚
27 CONNECT 153600 ● ● ● ● ✚
28 CONNECT 102400 ● ● ● ● ✚
29 CONNECT 61440 ● ● ● ● ✚
30 CONNECT 51200 ● ● ● ● ✚
31 CONNECT 624000 ● ● ● ● ✚
32 CONNECT 124800 ● ● ● ● ✚
33 CONNECT 62400 ● ● ● ● ✚
34 CONNECT 41600 ● ● ● ● ✚
35 CONNECT 31200 ● ● ● ● ✚ ✚ ✚
36 CONNECT 24960 ● ● ● ● ✚
37 CONNECT 20800 ● ● ● ● ✚
38 CONNECT 33600 ● ● ● ● ✚ ✚ ✚
39 CONNECT 28800 ● ● ● ● ✚ ✚ ✚
40 CONNECT 26400 ● ● ● ● ✚ ✚ ✚
41 CONNECT 24000 ● ● ● ● ✚ ✚ ✚
42 CONNECT 21600 ● ● ● ● ✚ ✚ ✚
Note: If error control result codes are enabled (X5, X6 or X7), the result-
ing message will be formatted as:
X5: CONNECT DTE speed/Link speed/Error control level
*
X6: CONNECT Link speed/ARQ
X7: CONNECT Link speed/ARQ/Error control level
*
whereas ARQ denotes that Automatic Retransmission reQuest type
of error control is enabled.
Result Codes for
ATV0
ATV1
X0 X1 X2 X3 X4 X5 X6 X7
