ES-2108 Series User’s Guide
68 Chapter 7 Basic Setting
7.7 IP Setup
Use the IP Setup screen to configure the default gateway device, the default domain name
server and add switch IP address.
7.7.1 Management IP Addresses
The switch needs an IP address for it to be managed over the network. The factory default IP
address is 192.168.1.1. The subnet mask specifies the network number portion of an IP
address. The factory default subnet mask is 255.255.255.0.
You can configure up to 64 IP addresses which are used to access and manage the switch from
the ports belonging to the pre-defined VLAN(s).
Note: You must configure a VLAN first.
Figure 30 IP Setup
Apply Click Apply to save the settings.
Cancel Click Cancel to reset the fields to your previous configuration.
Table 10 Switch Setup (continued)
LABEL DESCRIPTION
