The following table describes the labels in this screen.
Table 10 Switch Setup
LABEL
DESCRIPTION
VLAN Type
Choose 802.1Q or Port Based. The VLAN Setup screen changes depending on
whether you choose 802.1Q VLAN type or Port Based VLAN type in this screen.
IGMP Snooping Select Active to enable IGMP snooping have group multicast traffic only forwarded
to ports that are members significantly reducing multicast traffic passing through
your switch. See
for more information on IGMP snooping.
MAC Address
Learning
MAC address learning reduces outgoing traffic broadcasts. For MAC address
learning to occur on a port, the port must be active.
Aging Time
Enter a time from 10 to 3000 seconds. This is how long all dynamically learned MAC
addresses remain in the MAC address table before they age out (and must be
relearned).
GARP Timer:
Switches join VLANs by making a declaration. A declaration is made by issuing a
Join message using GARP. Declarations are withdrawn by issuing a Leave
message. A Leave All message terminates all registrations. GARP timers set
declaration timeout values. See the chapter on VLAN setup for more background
information.
Join Timer
Join Timer sets the duration of the Join Period timer for GVRP in milliseconds. Each
port has a Join Period timer. The allowed Join Time range is between 100 and
65535 milliseconds; the default is 200 milliseconds. See the chapter on VLAN setup
for more background information.
Leave Timer
Leave Time sets the duration of the Leave Period timer for GVRP in milliseconds.
Each port has a single Leave Period timer. Leave Time must be two times larger
than Join Timer; the default is 600 milliseconds.
Leave All Timer
Leave All Timer sets the duration of the Leave All Period timer for GVRP in
milliseconds. Each port has a single Leave All Period timer. Leave All Timer must be
larger than Leave Timer; the default is 10000 milliseconds.
Priority Queue
Assignment
IEEE 802.1p defines up to eight separate traffic types by inserting a tag into a MAC-
layer frame that contains bits to define class of service. Frames without an explicit
priority tag are given the default priority of the ingress port. Use the next two fields to
configure the priority level-to-physical queue mapping.
The switch has four physical queues that you can map to the 8 priority levels. On the
switch, traffic assigned to higher index queues gets through faster while traffic in
lower index queues is dropped if the network is congested.
Priority Level
(The following descriptions are based on the traffic types defined in the IEEE 802.1d
standard (which incorporates the 802.1p).
Level 7
Typically used for network control traffic such as router configuration messages.
Level 6
Typically used for voice traffic that is especially sensitive to jitter (jitter is the
variations in delay).
Level 5
Typically used for video that consumes high bandwidth and is sensitive to jitter.
Level 4
Typically used for controlled load, latency-sensitive traffic such as SNA (Systems
Network Architecture) transactions.
Level 3
Typically used for “excellent effort” or better than best effort and would include
important business traffic that can tolerate some delay.
Level 2
This is for “spare bandwidth”.
Level 1
This is typically used for non-critical “background” traffic such as bulk transfers that
are allowed but that should not affect other applications and users.
Level 0
Typically used for best-effort traffic.
