ES-2108 Series User’s Guide
Chapter 4 The Web Configurator 47
Advanced
Application
VLAN This link takes you to screens where you can configure port-based or 802.1Q VLAN
(depending on what you configured in the Switch Setup menu).
Static MAC
Forwarding
This link takes you to screens where you can configure static MAC addresses for a
port. These static MAC addresses do not age out.
Filtering This link takes you to a screen to set up filtering rules.
Spanning Tree
Protocol
This link takes you to screens where you can configure the STP/RSTP to prevent
network loops.
Bandwidth
Control
This link takes you to screens where you can cap the maximum bandwidth allowed
from specified source(s) to specified destination(s).
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
Mirroring This link takes you to screens where you can copy traffic from one port or ports to
another port in order that you can examine the traffic from the first port without
interference
Link Aggregation This link takes you to a screen where you can logically aggregate physical links to
form one logical, higher-bandwidth link.
Port
Authentication
This link takes you to a screen where you can configure RADIUS (Remote
Authentication Dial-In User Service), a protocol for user authentication that allows
you to use an external server to validate an unlimited number of users.
Port Security This link takes you to a screen where you can activate MAC address learning and
set the maximum number of MAC addresses to learn on a port.
Queuing Method This link takes you to a screen where you can configure SPQ or WRR with
associated queue weights for each port.
IP Application
Static Route This link takes you to screens where you can configure static routes. A static route
defines how the switch should forward traffic by configuring the TCP/IP parameters
manually.
DiffServ This link takes you to screens where you can enable DiffServ and set DSCP-to-
IEEE802.1p mappings.
Advanced
Management
Maintenance This link takes you to screens where you can perform firmware and configuration file
maintenance as well as reboot the system.
Access Control This link takes you to screens where you can change the system login password
and configure SNMP and remote management.
Diagnostic This link takes you to screens where you can view system logs and test port(s).
Cluster
Management
This link takes you to a screen where you can configure clustering management and
view its status.
MAC Table This link takes you to a screen where you can view the MAC addresses (and types)
of devices attached to what ports and VLAN IDs.
ARP Table This link takes you to a screen where you can view the MAC addresses – IP
address resolution table.
Table 5 Navigation Panel Links (continued)
LINK DESCRIPTION
